Multi
Drone docking
Vehicle
Mountable
2s-4s
Compatible
BotBay
Remote flight
Q100
Remote maintenance
The HEISHA FPV Dock Lite is a compact, vehicle-mountable drone docking station capable of remotely charging FPV drones powered by 2s-4s LiPo batteries, irrespective of the drone’s model or brand. Compatible with the HEISHA BotBay Flight Operating System, it allows users to remotely control FPV drones for waypoint, point-to-point, or manual flight missions, eliminating concerns about takeoff, landing, and recharging.
The HEISHA Q100 remote maintenance system can monitor and diagnose flight errors as long as there is WiFi access, enabling the restart of any components without the need for on-site personnel.
Furthermore, the HEISHA FPV Dock Lite is designed to be open and can integrate with flight operating systems other than the HEISHA BotBay.
A flexible compact dock for FPV drones
FPV Dock Lite- Single drone version
The HEISHA FPV Dock Lite single drone version can be flexibly deployed on a car rooftop or on flat ground. With dimensions of just 65 cm in width and 36 cm in height, you can easily drive around and park it in any underground parking lot.
65cm
Width
36cm
Height
FPV Dock Lite- 4 drone version
The HEISHA FPV Dock Lite four-drone version enables the simultaneous docking and charging of up to four drones. This significantly increases the number of optional FPV drones and substantially alleviates concerns about drone availability, which is particularly important for FPV drone enthusiasts, especially during racing competitions or events.
✓ 3-YEAR UPGRADE AND HIGHLY RECOMMENDED BY POLICE Bureaus
Specifications
| Single drone model | Four drone model | |
| Material | Aluminium alloy | Aluminium alloy |
| Compatible models | Mavic 3, Mini 3, Air 2s small drone | M30, Mavic 3 enterprise, all small drone |
| Weight | 35kg | 110kg |
| Dimension (opened) | 1300mm*650mm*360mm (L×W×H) | 2800*1050*450mm (L×W×H) |
| Dimension (closed) | 710mm*650mm*360mm (L×W×H) | 185cm×105cm×55cm (L×W×H) |
| AC | No | Include |
| PTC | No | Can be added |
| Backup power | No | Can be added |
| Open SDK | No | Yes |
| Precision landing | No | Yes |
| Software | FreeSky, BotBay, FlytBase | FreeSky, BotBay, FlytBase |
| Customize | No | Yes |
